Yaber K2s - Page 4

Install the TV Dongle
1. Push once to open the lid, and take out the tray.
2. Mount the TV Dongle and make sure the Micro HDMI port downside and the Micro
USB port upside.
Micro USB port
(Mark on the Back)
Micro HDMI port
(Mark on the Back)
Mounted TV Dongle
3. Insert the mounted TV Dongle into the slot.
4. Plug the USB power cable into the Micro USB port, and push to close the lid.
USB Power
Cable
Lid
Tray
TV Dongle Slot
