Yale Keyfree

Keyfree
Fixing Cylinder
Ⓔ
Ⓔ
➞
Ⓕ
Fitting the Handing Screw
➞ ➞
Left Handle Door Right Handle Door
※ Before fitting Key Free, the handing screw must be fitted. Failure to so will allow the outside lever to rotate. Only use
the handing screw provided which is attached to the underside of the outside lever in a bag with a yellow warning label.
※ Lightly tighten
the cylinder
fixing screw.
Installation Guide
Ⓜ
Ⓜ
Ⓐ
Ⓐ
Ⓐ
Ⓐ
Ⓐ
Ⓐ
Ⓐ
Ⓐ
Ⓐ
Ⓐ
Ⓐ
Ⓐ
Ⓐ
Ⓐ
Ⓐ
Ⓐ
Ⓐ
Ⓐ
Ⓐ
Cylinder fixing screw
Fitting the Spindle
➞ ➞
Contents
Contents Include
Fixing Cylinder
Fitting The Spindle
Fitting The Handing Screw
Installation
Check Points after Installation
1
2
3
5
Registering Your PIN Code
Registering Your Remote Controls (Optional)
Securely Locking your door
Opening Your Door
6
7
1 2
Quick Guide
Installation Guide
Contents Include
Ⓐ Ⓑ Ⓒ Ⓓ
Ⓔ Ⓕ
Ⓖ Ⓗ Ⓘ
Ⓙ
Ⓚ
Ⓛ
Ⓜ
Ⓝ
※ Fit Key Free using hand Philips screw driver to avoid cross threading fixing screws.
If using a cordless, please ensure it is set to low speed & torque.
M6: Thick & Short Screw×2
M4: Small
Screw
M4: Smallest
Screw
M6: Thick & Medium Screw×1
M5: Thin & Longest Screw×2
Ⓖ
ⒽⒷ
※ Insert the spindle
into the main unit.
※ After fully inserting the spindle,
push the snap fit washer down
until ‘click’ sound is heard.
※ Check that the spindle
free rotates.
※Ⓖ, Ⓗcould be assembled
already on Ⓑ (main unit).
※ In case that the main unit includes the spindle already, please skip step .
