Yale Nest x Yale User Manual

P/N -540-INST-FUL Rev 4AYRD
2
1"
[25mm]
Dia.
C
L
FOLD OVER DOOR EDGE
C
L
C
L
C
L
C
L
1"
[25mm]
Dia.
2-1/8"
[54mm]
Thru Hole
Dia
2-1/8"
[54mm]
Thru Hole
Dia
CAUTION:
If printed from electronic
Measure ruler to check scale
file set print s 1:1cale to
2" 1" 0"
50mm
25mm
0"
25mm
50mm
75mm
2"
3"
1"
CUT LINE
For 1-3/8"
[35mm]
Thick Door
2-3/8" [60mm] Backset
2-3/4" [70mm] Backset
For 1-3/4"
[44.5mm]
Thick Door
Template
Tools Needed
Utility Knife
Drill
Wood Mortise
Chisel
Pencil
Tape
Measure
Level
Provided Fasteners
Standard
Phillips Head
Screwdriver
OR
OR
Silver
for
2 to 2-1/4"
Door Thickness
Black
forStandard
1-3/4"
Door Thickness
Green
for
1-3/8"
Door Thickness
Strike Plate
and
Latch Screws
Inside Lock
Screws
Tools necessary only for new doors
or adjusting existing prep.
Optional
Security
Strike Plate
Screws
