Yale RL Series User Manual

3
2X 1/4"
Thru For
RL255 and RL255D
Functions
2X Center Punch at
This Location For
RL255S Function
Screws
Note: See Door Marker on page 4 for all other functions.
Dummy Functions
RL255, RL255D & RL255S Functions
1"
2"
3"
5"
4"
3"
2" 1"
An ASSA ABLOY Group brand
80-9510-0070-000 (03-16)
