Inside the Box
Glossary of Terms
DVR – Digital Video Recorder and Network Video Recorder
BNC – Bayonet Neill–Concelman, Video Inputs connecting the HD Cameras to the DVR, You may see 4 or
8 BNC ports depending on the model purchased.
HDMI – High Definition Multi-media Interface connects your DVR to a TV or PC Monitor.
VGA – Video Graphics Array connects your DVR to a TV or PC Monitor (not supplied).
HD – High Definition. 720 & 1080 are both High Definition video quality.
PTZ – Pan, Tilt & Zoom. Movable camera with Zoom functionality.
HDD – Hard Disk Drive. Where the video footage is stored within the DVR.
TB – Terabyte. Amount of storage space within the HDD (e.g. 1TB/2TB).
QR Code – Quick Response Code. Scan this using the Yale CCTV App for quick pairing.
Note – none of the Yale HD CCTV systems connect into a laptop for viewing video images.
1. DVR with pre-installed Hard Drive
2. HD Cameras
3. BNC Cables
4. Power Adaptors
5. Splitter
6. Ethernet Cable
7. HDMI Cable
8. Mouse
9. Fixing Pack
