14
6. Adding Accessories
To provide additional protection you can add extra Door/Window Contacts, PIRs, Keypads, Remote
Key Fobs & Panic Buttons. These are available from local stockists or www.yalehome.co.uk
1
Adding devices to an already
installed system
The installed system will be controlled by a Keypad.
Keypad
1 Enter Setting mode: Press Panic button A followed by
the PIN code
(Indicated by a continuously flashing LED.)
2 Switch OFF system tamper: Press Panic button A
followed by 2
(The Siren will beep in response.)
3 Enter learn mode: Press Panic button A followed by 4 .
(The Siren will beep and flash in response.)
4 Learning: Press device learn/test buttons (see section
3, step 3) to trigger learning-in signals.
(The Siren will beep and flash when each device is learnt in.)
5 Exit learn mode: When all the devices have been learnt
in, press Panic button A and 5 to quit learn mode.
6 Switch ON system tamper: Press Panic button A and 3
to rearm tamper protection.
7 Exit Setting mode: Press Disarm twice to exit.
(The Keypad LED will now stop flashing.)
Factory Reset
To remove an accessory, it is necessary to clear the
memory of the Siren. To do this, a factory reset needs to
be performed as follows.
1 Whilst Siren is powered ON
2 Move Dip Switch 1 to the ON position
3 Wait for 30 seconds
4 Move Dip Switch 1 back to the OFF position.
Press
ENTER ****
Press
ENTER
Press
ENTER
Press
ENTER
Press
ENTER
Press
x 2
30secs
4
3
2
1
ON
OFF
4
3
2
1
ON
OFF
After performing a factory reset ALL accessories will
be removed and it will be necessary to reprogram the
Siren and LEARN in all required accessories.
