5
Remove battery saver tab to activate batteries by unscrewing the keypad cover by the screw at the bottom
of the keypad
Arm Disarm
Part Arm
Panic Button A Panic Button B
Green LED light
2. Overview of Alarm Components - The Keypad
Bracket to clip into
back of keypad for
tabletop use
Ports for bracket
x 3
Rubber strip
Battery compartment screws x 1.
Unscrew to open battery compartment to
remove battery saver tab before first use.
Fixing slots x 2 for
wall mounting
1
