Yale YRD210

4
An ASSA ABLOY Group brand
P/N AYRD210-INST-FUL Rev B
Lock Installation
 #2 Phillips screwdriver
Door Prep
 2-1/8" (54mm) hole saw
 1" (26mm) boring bit
 7/64" (2.5mm) drill bit
 Chisel & hammer
Parts Illustrations
Tools Needed
Quick Start Guide
Installation Instructions
Door Marker
Outside Escutcheon
Bolt
Strike Plate
Screw Pack
Keys
Included in the box. . .
COMPONENTS AND TOOLS
Inside Escutcheon
Inside Mounting Plate
Battery Cover
4 AA Alkaline Batteries
INSTALLATION
Outside
Escutcheon
Inside
Escutcheon
4 AA Alkaline
Batteries
(2) Through
bolts
(4) screws
Keys
Battery Cover
Bolt
Strike Plate
Inside
Mounting
Plate
(3) Mounting
screws
