Yamaha 150A - Page 34

2-15
SPEC
E
MAINTENANCE SPECIFICATIONS
STARTER MOTOR
Type Bendix
Output kW 1.1
Rating Second 30
Brushes
Standard length mm (in) 16.0 (0.63)
Wear limit mm (in) 12.0 (0.47)
Commutator
Standard diameter mm (in) 33.0 (1.30)
Wear limit mm (in) 31.0 (1.22)
Mica
Standard undercut mm (in) 0.8 (0.03)
Wear limit mm (in) 0.2 (0.01)
CHARGING SYSTEM
Lighting coil
Output peak voltage lower
limit (G – G)
@ cranking 1 V — —
@ cranking 2 V — —
@ 1,500 r/min V 35 20
@ 3,500 r/min V 85 50
POWER TRIM AND TILT
SYSTEM
Trim sensor
Resistance (P – B) Ω 582 - 873
Resistance (O – B) Ω 800 - 1,200
POWER TRIM AND TILT
MOTOR
Fluid type ATF Dexron II
Brushes
Standard length mm (in) 9.8 (0.39)
Wear limit mm (in) 4.8 (0.19)
Commutator
Standard diameter mm (in) 22.0 (0.87)
Wear limit mm (in) 21.0 (0.83)
Mica
Standard undercut mm (in) 1.35 (0.05)
Wear limit mm (in) 0.85 (0.03)
* Cranking 1: Open circuit voltage.
Cranking 2: Loaded circuit voltage.
Item Unit
Model
Oil injection
(and 225DET)
Pre-mix
(except for 225DET)
