MAIN COMPONENTS
1 Top cowling
2 Cowling lock lever
3 Cooling water pilot hole
4 Tilt lock lever
5 Recoil starter handle
6 Gear shift lever
7 Engine stop button/
Engine stop lanyard switch
8 Throttle control grip
9 Throttle friction knob
0 Clamp screw
q Starter button
w 2P connector
e Choke knob
r Rope attachment
t Clamp braket
y Trim angle adjusting rod
u Anti-cavitation plate
i Cooling water inlet
o Propeller
p Fuel tank
a Remote control box
* May not be exactly as shown; also may not
be included as standard equipment on all
models.
*
*
*
*
*
*
*
