CHARGING SYSTEM
8-13
EAS27230
TROUBLESHOOTING
The battery is not being charged.
NOTE:
• Before troubleshooting, remove the following part(s):
1.Seat
2.Front cowling inner panel
3.Fuel tank
NG→
OK↓
NG→
OK↓
NG→
OK↓
NG→
OK↓
NG→
OK↓
1. Check the fuse.
(Main)
Refer to "CHECKING THE
FUSES" on page 8-113.
Replace the fuse.
2. Check the battery.
Refer to "CHECKING AND
CHARGING THE BATTERY" on
page 8-114.
• Clean the battery terminals.
• Recharge or replace the battery.
3. Check the stator coil.
Refer to "CHECKING THE STA-
TOR COIL" on page 8-124.
Replace the stator coil assembly.
4. Check the rectifier/regulator.
Refer to "CHECKING THE REC-
TIFIER/REGULATOR" on page 8-
124.
Replace the rectifier/regulator.
5. Check the entire charging sys-
tem’s wiring.
Refer to "CIRCUIT DIAGRAM" on
page 8-1.
Properly connect or repair the charg-
ing system’s wiring.
Replace the rectifier/regulator.
To Next Page
