SIGNALING SYSTEM
8-23
NG→
OK↓
NG→
OK↓
NG→
OK↓
The neutral indicator light fails to come.
NG→
OK↓
NG→
OK↓
NG→
OK↓
3. Check the hazard switch.
Refer to "CHECKING THE
SWITCHES" on page 8-109.
Replace the left handlebar switch.
4. Check the turn signal/hazard
relay.
Refer to "CHECKING THE
RELAYS" on page 8-117.
The turn signal relay is faulty and must
be replaced.
5. Check the entire signaling sys-
tem’s wiring.
Refer to "CIRCUIT DIAGRAM" on
page 8-1.
Properly connect or repair the signal-
ing system’s wiring.
This circuit is OK.
1. Check the neutral indicator light
bulb and socket.
Refer to "CHECKING THE LEDS"
on page 8-113.
Replace the neutral indicator light
bulb, socket or both.
2. Check the neutral switch.
Refer to "CHECKING THE
SWITCHES" on page 8-109.
Replace the neutral switch.
3. Check the starting circuit cut-off
relay.
Refer to "CHECKING THE
RELAYS" on page 8-117.
Replace the starting circuit cut-off
relay.
To Next Page
