2-6
E
EMU01293
Throttle friction adjusting screw/ knob
A friction device in the tiller handle pro-
vide resistance to movement of the throt-
tle grip.
This is adjustable for operator preference.
An adjusting screw/knob is located within
the tiller handle.
When constant speed is desired, tighten
the adjusting screw/bolt to maintain the
desired throttle setting.
w
Do not over tighten the friction adjusting
screw/ knob.
If there is too much resistance, it may be
difficult to move the throttle grip, which
could result in an accident.
Resistance Knob/Screw
Increase Turn clockwise
Decrease Turn counterclockwise
EMC42010
CHOKE KNOB
Pulling out this knob (setting it to ON)
supplies a rich mixture required to start
the engine.
NOTE:
The choke knob for Remote control model
has the same function as the choke switch
on the remote control box.
305022*
305023*
25 25-3/30
EMC44010
RECOIL STARTER HANDLE
(If equipped)
Pull the handle gently until resistance is
felt. Then vigorously pull the handle
straight out to crank the engine to start it.
6L2-9-1H 2 4/20/01 1:53 PM Page 7
