2-7
E
EMD00011
STEERING FRICTION ADJUSTING
SCREW(for Tiller control model)
A friction device provides resistance to
steering movement. This is adjustable for
operator preference. An adjusting
screw/bolt is located on the swivel brack-
et.
EMD00310*
Adjustment
w
Do not overtighten the friction
screw/bolt.
If there is too much resistance, it may be
difficult to steer, which could result in an
accident.
Resistance Screw/bolt
Increased Turn clockwise
Decreased Turn counterclockwise
408015
