Components
17
EMU25891
Open
With the lever/knob in this position, fuel flows
to the carburetor.
Normal running is done with the lever/knob in
this position.
EMU25901
Open
The fuel cock has two open positions, one for
selecting fuel flow from the built-in fuel tank,
and one for an external tank.
Fuel flows to the carburetor with the lever or
knob in either open position. These are the
normal running positions.
EMU25911
Tiller handle
To change direction, move the tiller handle to
the left or right as necessary.
EMU25922
Gear shift lever
Pulling the gear shift lever towards you puts
the engine in forward gear so that the boat
moves ahead. Pushing the lever away from
you puts the engine in reverse gear so that the
boat moves astern.
1. Close position
1. Close position
1. Open position
1. “OPEN” position for the built-in tank
2. “OPEN” position for the portable tank
U6E028E0.book Page 17 Tuesday, February 10, 2009 3:19 PM
