Yamaha 4ACMH User Manual

3-17
REMOTE CONTROL TYPES AND APPLICATIONS
6X7 CONCEALED REMOTE CONTROL DIMENSIONS
213 (8.39)
ECM bracket
116 (4.57)
M6 tapping mount screw
F
N
R
Throttle range
Throttle range
Shift
range
Shift
range
22.5
deg.
22.5
deg.
Max.
67 deg.
Max.
90 deg.
Template
* Stop SW wire harness length:
Approx. 2 m (6.5 ft)
* ECM wire harness length:
Approx. 1.5 m (5 ft)
170 (6.69)
130 (5.12)
155 (6.10)
59.5 (2.34)
16.5
(0.65)
40.5
(1.59)
43
(1.69)
56.5 (2.22) 6.4 (0.25)
35 (1.38)
38 (1.50)
54.4
(2.14)
Make three 7 mm (9/32 in) holes for mounting with bolts and nuts.
Drill 4 mm (5/32 in) holes for tapping screws, if the board is thicker
than 20 mm (0.79 in).
12.7
(0.50)
17.5
(0.69)
39.5
(1.56)
27 (1.06)
57
(2.24)
18
(0.71)
96.2
(3.79)
95 (3.74) 95 (3.74) 95 (3.74)
Mount board
mm (in.)
