3-31

REMOTE SWITCH TYPES AND APPLICATIONS

STATION SELECTOR SWITCH

Ref. No. Part No. Description

1 6X6-82570-A0 For Digital Network System (6Y8), Dual station

2 6X6-82570-B0 For Digital Network System (6Y9), Dual station, Single/Twin/Triple engine application

3 6X6-82570-L0 For Digital Network System (6Y9), Dual station, Quad engine application only

mm (in.)

B B B

GGG

66 (2.60)

49 (1.93)

68 (2.68)

51 (2.01)

5.5 (0.22)

110 (4.33)

100 (3.94)

GGG

37.2

(1.46)

(0.87)

61.5 (2.42) 12 (0.47)

55 (2.17)

38.1 (1.5)

50 (1.97)

33.4 (1.31)

5.6 (0.22)

38.4

(1.51)

200 (7.87)

61.5 (2.42)

(0.47)
