3-40
STEERING HOOK
To be continued.
Part No.
6
3D-48511-01
Global model
40V
50
H
FT50C
F50D
US/CA model
For STR guide
Part No.
67F-48511-01
Global model
F75B
F80B
F90B
F100D
US/CA model
F75A
F90A
For STR guide
Part No.
688-48511-12
Global model
75A
85
A
75C
90A
US/CA model
For STR guide
Part No.
68V-48511-01
Global model
F75
C
F95A
F
100B
F115A
US
/
CA
m
od
e
l
F115A
For STR guide
Part No.
676-48511-02
Global model
6C
8C
E8D
EK8D
US/CA model
For ball post
Part No.
6J8-48511-01
Global model
30D
US/CA model
For ball post/ STR guide
