3-43
STEERING GUIDE ATTACH
MENT KIT
Part No.
6BG-61350-00
Global model
F20D
F25D
FT
25F
F30B
F40F
US/CA model
F25A
T25A
F30A
F40A
Part No.
697-61350-00
Global model
55B
US/CA model
Part No.
67F-61350-00
Global model
F75B
F80B
F90B
F100D
US/CA model
F75A
F90A
(1)
(1)
(1)
Part No.
688-61350-10
Global model
60F
70B
75C
90A
75A
US/CA model
Global model
85A
E60H
US/CA model
Part No.
6E5-61350-02
Global model
F75
C
F95A
F
100B
US/CA model
Global model
115 – 250
F115 – F300 (V6)
US/CA model
Part No.
6
EK-61350-00
Global model
F115B
US/CA/
ANZ mode
l
F115B
(1)
(1)
(1)
130
132
