Yamaha 4ACMH User Manual

5-43
Fuse
Trim meter
6Y7-83670-40 (BLK)
-50 (WHT)
Lamp switch
SpeedometerCharge
warning unit
Water pressure
meterVoltage meterDigital hour meter
Mechanical
hour meterFuel meter
Thermo sensor Fuel sensor
Engine is
running
Main switch is
“ON”
Water temperature
meter
Charge lamp
Tachometer
6Y7-83540-80 (BLK)
-90 (WHT)
Y
A
MA
H
A
6Y5-83553-00 : 2.5 m (8 ft)
6Y5-83653-00 : 5 m (16 ft)
-10 : 6 m (19 ft) -20 : 7 m (23 ft) -30 : 8 m (26 ft) -40 : 9 m (29 ft) -50 : 10.5 m (34 ft)
6Y5-82521-00 6Y5-82149-00 6Y5-82117-00
688-82520-00
WIRING DIAGRAMS
ANALOG METER (6Y7)
2- AND 4-STROKE ENGINES
Above 40 [3-cyl.] w/ oil injection (except L/250G),
Above F30 (Mechanical RC)

Yamaha 4ACMH Specifications

General

Brand	Yamaha
Model	4ACMH
Category	Outboard Motor
Language	English
