6-15
P
Multi-sensor (OP)
Speed sensor
FUEL TANK 2
FUEL TANK 1
FUEL
TACH(C)
TACH(S)
TACH(P)
SPEED
Coolant press.
sensor (OP)
ECM
Trim
sensor
Coolant press.
sensor (OP)
ECM
Trim
sensor
C
S
Coolant press.
sensor (OP)
ECM
Trim
sensor
Fuse (10A)
(+)
(GND)
NMEA
0183
GPS
Multi-hub
Multi-hub
Multi-hub
Multi-hub
Resistor
Cap
Cap
Cap
Cap
Resistor
Cap
Cap
NETWORK WIRING DIAGRAMS
FUEL INJECTED F30-
F250 [Mechanical RC]
& HPDI ENGINES
TRIPLE ENGINE APPLICATION
228
