Yamaha 4ACMH User Manual

7-17
NETWORK WIRING DIAGRAMS
SINGLE STATION W/ 6Y8 GAUGE SINGLE ENGINE APPLICATION (6X6 binnacle
mount Digital Electronic Control)
Ref.
No.
Part name Part No. Remarks
1 Main-harness (16P)
6X6-8258A-10 7 m (23 ft) 6X6-8258A-20 8 m (26 ft) 6X6-8258A-30 10 m (32 ft) 6X6-8258A-40 12 m (38 ft)
9 Fuel tank/ GPS wire 6Y8-8356N-01 0.3 m (1 ft)
12 Main bus wire
6Y8-82553-01 0.3 m (1 ft) 6Y8-82553-50 3 m (10 ft) 6Y8-82553-11 4.5 m (15 ft) 6Y8-82553-21 6.1 m (20 ft) 6Y8-82553-31 7.6 m (25 ft) 6Y8-82553-41 9.1 m (30 ft)
13 Pigtail bus wire
6Y8-82521-01 0.3 m (1 ft) 6Y8-82521-11 0.6 m (2 ft) 6Y8-82521-21 0.9 m (3 ft) 6Y8-82521-31 1.8 m (6 ft) 6Y8-82521-41 2.7 m (9 ft) 6Y8-82521-51 3.6 m (12 ft)
14
System power supply wire
6Y8-83553-01 w/ 10-amp fuse, 2.4 m, 8 ft
16 Multi-hub 6Y8-81920-01 w/ resistor cap, Black 17 Single (inline) hub 6Y8-81920-11 w/ resistor, 4-6P, White 19 Transom multi-sensor 6Y8-83688-01
Depth, speed, water temp, w/ 4.9 m (15 ft) wire
22 Immobilizer unit
6Y8-86254-02 EU 6Y8-86254-22 US, ANZ 6Y8-86254-30 JP
29
6X6 binnacle mount Digital Electronic Con- trol
6X6-48205-34 Single station
40 Main switch 6X6-82570-31
For 6X6 binnacle mount Digi- tal Electronic Control, Main station helm
Ref.
No.
Part name Part No. Remarks
