NETWORK WIRING DIAGRAMS
DUAL STATION W/ 6Y8 GAUGE TWIN ENGINE APPLICATION
Ref.
No.
Part name Part No. Remarks
1 Main-harness (16P)
6X6-8258A-10 7 m (23 ft) 6X6-8258A-20 8 m (26 ft) 6X6-8258A-30 10 m (32 ft) 6X6-8258A-40 12 m (38 ft)
9 Fuel tank/ GPS wire 6Y8-8356N-01 0.3 m (1 ft)
12 Main bus wire
6Y8-82553-01 0.3 m (1 ft) 6Y8-82553-50 3 m (10 ft) 6Y8-82553-11 4.5 m (15 ft) 6Y8-82553-21 6.1 m (20 ft) 6Y8-82553-31 7.6 m (25 ft) 6Y8-82553-41 9.1 m (30 ft)
13 Pigtail bus wire
6Y8-82521-01 0.3 m (1 ft) 6Y8-82521-11 0.6 m (2 ft) 6Y8-82521-21 0.9 m (3 ft) 6Y8-82521-31 1.8 m (6 ft) 6Y8-82521-41 2.7 m (9 ft) 6Y8-82521-51 3.6 m (12 ft)
16 Multi-hub 6Y8-81920-01 w/ resistor cap, Black 19 Transom multi-sensor 6Y8-83688-01
Depth, speed, water temp, w/ 4.9 m (15 ft) wire
22 Immobilizer unit
6Y8-86254-02 EU 6Y8-86254-22 US, ANZ 6Y8-86254-30 JP
27
2nd helm harness (2-12P)
6X6-8258A-B1 5 m (16 ft)
6X6-8258A-D1 8 m (26 ft)
6X6-8258A-F1 12 m (38 ft)
28
2nd helm harness (3/4/6P)
6X6-8258A-G1 5 m (16 ft)
6X6-8258A-H1 8 m (26 ft)
6X6-8258A-J1 12 m (38 ft)
33
6X6 binnacle mount Digital Electronic Con- trol
6X6-48207-44
Dual station/ Main station helm
34
6X6 binnacle mount Digital Electronic Con- trol
6X6-48207-53 Dual station/ 2nd station helm
42 Engine shut-off switch 6X6-82570-90 2nd station helm 44 Main switch 6X6-82570-40 Main station helm 45 Start/stop button 6X6-82570-60 Main station helm 46 Start/stop button 6X6-82570-E0 2nd station helm 53 All start/stop button 6X6-82570-C0
For single/twin/triple engine application
54 Station selector switch 6X6-82570-B0
For dual station, single/twin/ triple engine application
