Yamaha 4ACMH User Manual

1-22
OUTBOARD MOTOR DIMENSIONS
OVERALL DIMENSIONS (4-STROKE)
Global model
(US, CA,
ANZ model)
Symbol
F/FL225FET
(F/LF225CA)
F/FL250DET
(F/LF250CA)
F/FL300BET
(F/LF300CA)
F/FL350AET
(F/LF350CB)
L1 mm (in) 728 (28.7) 776 (30.6)
L2 mm (in) 230 (9.1) 255 (10.0)
L3 mm (in) — —
L4 mm (in) 673 (26.5) 732 (28.8)
L5
S
mm (in)
——
L——
X 59 (2.3) 48.4 (1.9)
U 59 (2.3) 48.4 (1.9)
L6
S
mm (in)
——
L——
X 1155 (45.5) 1193 (47.0)
U 1272 (50.1) 1310 (51.6)
L7 mm (in) 639 (25.2) 712 (28.0)
L8 mm (in) 240 (9.4) 258 (10.2)
L9
S
mm (in)
——
L——
X 53 (2.1) 56 (2.2)
U 59 (2.3) 62 (2.4)
L10 mm (in) 75 (3.0) 73 (2.9)
H1
S
mm (in)
——
L——
X 1078 (42.4) 1098 (43.2)
U 1205 (47.4) 1225 (48.2)
H2 mm (in) 812 (32.0) 909 (35.8)
H3 mm (in) 216 (8.5) 229 (9.0)
H4
S
mm (in)
——
L——
X 643 (25.3) 637 (25.1)
U 770 (30.3) 764 (30.1)
H5 mm (in) — —
H6
S
mm (in)
——
L——
X 847 (33.3) 864 (34.0)
U 924 (36.4) 941 (37.0)
H7 mm (in) 510 (20.1) 588 (23.1)
H8 mm (in) 48 (1.9) 65 (2.6)
H9 mm (in) 951 (37.4) 1041 (41.0)
H10 mm (in) 45 (1.8) 49 (1.9)
H11
S
mm (in)
——
L——
X 25 (1.0) 26 (1.0)
U 25 (1.0) 26 (1.0)
W1 mm (in) 317 (12.5) 317 (12.5)
W2 mm (in) — —
W3 mm (in) — —
W4 mm (in) — —
W5 mm (in) 454 (17.9) 475.6 (18.7)
W6 mm (in) — —
A1 degree 32 32
A2 degree 67 70
A3 degree 3 3
T1 mm (in) 724 (28.5) 723.9 (28.5)
