OUTBOARD MOTOR DIMENSIONS
OVERALL DIMENSIONS (2-STROKE)
Global model
(US, CA model)
Symbol
E115AE
115BE
E115AET
115BET
140BET
115CETO 130BETO
L/150AET
L/200AET
Z150QETO
(VZ150TR)
L/250GETO
L1 mm (in) 539 (21.2) 539 (21.2) 542 (21.3) 554 (21.8) 543 (21.4) 613 (24.1) 566 (22.3)
L2 mm (in) 213 (8.4) 213 (8.4) 188 (7.4) 176 (6.9) 188 (7.4) 180 (7.1) 181 (7.1)
L3mm (in)———————
L4 mm (in) 616 (24.3) 616 (24.3) 616 (24.3) 632 (24.9) 634 (25.0) 646 (25.4) 673 (26.5)
L5
S
mm (in)
———————
L 80 (3.1) 80 (3.1) 70 (2.8) 70 (2.8) 49 (1.9) 53 (2.1) —
Y ———————
X 85 (3.3) 85 (3.3) 61 (2.4) 61 (2.4) 62 (2.4) — 69 (2.7)
U ——————89 (3.5)
L6
S
mm (in)
———————
L 1005 (39.6) 1005 (39.6) 1007 (39.6) 1007 (39.6) 1030 (40.6) 1034 (40.7) —
Y ———————
X 1120 (44.1) 1120 (44.1) 1124 (44.3) 1124 (44.3) 1144 (45.0) — 1155 (45.5)
U ——————1271 (50.0)
L7 mm (in) 482 (19.0) 482 (19.0) 468 (18.4) 463 (18.2) 569 (22.4) 574 (22.6) 631 (24.8)
L8 mm (in) 214 (8.4) 215 (8.5) 173 (6.8) 159 (6.3) 173 (6.8) 168 (6.6) 185 (7.3)
L9
S
mm (in)
———————
L — 12 (0.5) 44 (1.7) 31 (1.2) 54 (2.1) 42 (1.7) —
Y ———————
X — 12 (0.5) 53 (2.1) 40 (1.6) 62 (2.4) — 52 (2.0)
U ——————58 (2.3)
L10 mm (in) 64 (2.5) 64 (2.5) 74 (2.9) 74 (2.9) 74 (2.9) 74 (2.9) 73.8 (2.9)
H1
S
mm (in)
———————
L 929 (36.6) 929 (36.6) 928 (36.5) 928 (36.5) 946 (37.2) 947 (37.3) —
Y ———————
X 1056 (41.6) 1056 (41.6) 1054 (41.5) 1054 (41.5) 1072 (42.2) — 1077 (42.4)
U ——————1203 (47.4)
H2 mm (in) 508 (20.0) 508 (20.0) 544 (21.4) 544 (21.4) 631 (24.8) 746 (27.9) 710 (28.0)
H3 mm (in) 190 (7.5) 190 (7.5) 191 (7.5) 191 (7.5) 210 (8.3) 211 (8.3) 216 (8.5)
H4
S
mm (in)
———————
L 515 (20.3) 515 (20.3) 515 (20.3) 515 (20.3) 516 (20.3) 516 (20.3) —
Y ———————
X 642 (25.3) 642 (25.3) 642 (25.3) 642 (25.3) 642 (25.3) — 642 (25.3)
U ——————768 (30.2)
H5mm (in)———————
H6
S
mm (in)
———————
L 735 (28.9) 735 (28.9) 764 (30.1) 764 (30.1) 762 (30.0) 774 (30.5) —
Y ———————
X 810 (31.9) 810 (31.9) 839 (33.0) 839 (33.0) 837 (33.0) — 846 (33.3)
U ——————923 (36.3)
H7 mm (in) 150 (5.9) 150 (5.9) 180 (7.1) 191 (7.5) 205 (8.1) 308 (12.1) 242 (9.5)
H8 mm (in) 53 (2.1) 55 (2.2) 26 (1.0) 15 (0.6) 26 (1.0) 14 (0.6) 21 (0.8)
H9 mm (in) 730 (28.7) 730 (28.7) 730 (28.7) 741 (29.2) 788 (31.0) 945 (37.2) 818 (32.2)
H10 mm (in) 45 (1.8) 45 (1.8) 45 (1.8) 46 (1.8) 45.4 (1.8) 44 (1.7) 45.4 (1.8)
H11
S
mm (in)
———————
L — — 30 (1.2) 30 (1.2) 31 (1.2) 32 (1.3) —
Y ———————
X — — 30 (1.2) 30 (1.2) 31 (1.2) — 25 (1.0)
U ——————25 (1.0)
W1 mm (in) 297 (11.7) 300 (11.8) 291 (11.5) 291 (11.5) 301 (11.9) 277 (10.9) 281 (11.1)
W2 mm (in) — — — — — — —
W3 mm (in) 297 (11.7) 300 (11.8) 291 (11.5) 291 (11.5) — — —
W4 mm (in) — — — — — — —
W5 mm (in) 422 (16.6) 424 (16.7) 409 (16.1) 409 (16.1) 426 (16.8) 396 (15.6) 420 (16.5)
W6mm (in)———————
A1 degree 35 35 35 35 35 32 32
A2 degree 66 70 70 70 70 70 70
A3degree—444443
T1 mm (in) 660 (26.0) 660 (26.0) 660 (26.0) 660 (26.0) 660 (26.0) — 660 (26.0)
