6-13
(+)
(GND)
PS
ECM ECM
NMEA
0183
GPS
Multi-hub
Fuse (10A)
TACH(S) TACH(P)
FUEL/SPEED
FUEL TANK 1 FUEL TANK 2
Trim sensor Trim sensor
Coolant press. sensor (OP) Coolant press. sensor (OP)
Speed sensor
Single-hub with resistor Single-hub with resistor
NETWORK WIRING DIAGRAMS
FUEL INJECTED F30-F250 [Mechanical RC] & HPDI ENGINES
TWIN ENGINE APPLICATION (Simple)
