SPECIFICATIONS
Model
Unit 6CMH
Item
DIMENSIONS
Overall length mm (in.)
Overall width mm (in.)
Overall height S/L/X mm (in.)
Transom height S/L/X mm (in.)
Weight S/L/X kg (lb.)
PERFORMANCE
Full throttle operating range r/min
Maximum output kW @ r/min
Idling speed (in neutral) r/min
ENGINE
Type
Displacement cm
3
(cu.in.)
Bore
× stroke mm (in.)
Ignition system
Spark plug NGK
Spark plug gap mm (in.)
Control system
Starting system
Minimum battery capacity (20hour) V-Ah
Alternator output V-A (W)
Starting carburetion system
DRIVE UNIT
Gear positions
Gear ratio
Trim and tilt system
Propeller mark
FUEL AND OIL
Recommended fuel
Fuel tank capacity l (US gal, Imp gal)
Recommended engine oil
Lubrication
Fuel:oil ratio Fuel:Oil
Recommended gear oil
Gear oil capacity cm
3
(US oz, Imp oz)
TIGHTENING TORQUE
Spark plug N•m (kgf•m, lb•ft)
Propeller nut N•m (kgf•m, lb•ft)
802 (31.6)
343 (13.5)
977 (38.5)/1,104 (43.5)/—
436 (17.2)/563 (22.2)/—
27 (59.4)/27.5 (60.5)/—
4,000–5,000
4.4 @ 4,500
850–950
2-stroke, L2
165 (10.01)
50 × 42 (1.97 × 1.65)
CDI system
BR7HS-10
0.9–1.0 (0.035–0.039)
Tiller control
Manual start
—
12 (80)
Choke start
Forward-Neutral-Reverse
2.08 (27/13)
Manual tilt
N
Regular gasoline
12 (3.17, 2.64)
YAMALUBE 2 STROKE OUTBOARD OIL
or an equivalent TCW3 certified outboard oil
Premix
100:1
Hypoid gear oil (SAE90)
160 (5.41, 5.63)
25 (2.5, 18)
17 (1.7, 12)
