3-23
GB
EMU01201
PROCEDURE FOR TILTING UP
Power trim/tilt model
1) If there is a fuel joint or a fuel cock on
the boat, disconnect the fuel line or
close the fuel cock.
UP
DN
701034
UP
DN
403011
302021
DN
UP
2) Push the power trim/tilt switch “UP”
until the outboard has tilted up com-
pletely.
3) Turn the tilt-support lever toward you
and support the engine.
w
After tilting the engine, be sure to sup-
port it with the tilt-support lever. Other-
wise, the engine could fall back down
suddenly if oil in the power trim/tilt unit
should lose pressure.
6H2-9-7M-3B (GB,F,ES) 5/9/00 4:04 PM Page 26
