2-14
GB
EMD84012
OIL LEVEL WARNING / OIL FILTER
CLOGGING WARNING
This engine has an oil level warning sys-
tem.
If oil level falls below lower limit, the
warning device will activate.
(
2); Included (—); N/A
If the warning system has been activated,
stop the engine and check for the cause.
NOTE:
The warning for oil filter clogging is simi-
lar to the warnings for low oil level and
overheating.
For easy troubleshooting, it is advisable
to check for engine overheating first, then
oil level and finally oil filter clogging.
1 Oil filter
YAMAHA
x1000 r/min
0
1
3
4
5
6
7
801016
801****
5
1
2
3
4
x100
r/min
TACH
701054
213025
q
Warning device
activation
The engine speed
will automatically
decrease to about
2,000 r/min.
The oil level warning
indicator will come on.
The buzzer will sound.
Tiller Remote
control control
model model
— 2
— 2
— 2
