3-4
GB
EMF20010
FILLING FUEL AND
ENGINE OIL
EMF30011*
FILLING FUEL
1) Remove the fuel tank cap.
2) Fill the fuel tank carefully.
3) Close the cap securely after refueling.
Wipe up any spilled fuel.
EMF33011
FILLING OIL (for Autolube system
model)
This engine uses the YAMAHA AUTOL-
UBE SYSTEM, which provides superior
lubrication by ensuring the proper oil
ratio for all operating conditions. No fuel
premixing is needed (except during
break-in/running-in). Simply pour gaso-
line into the fuel tank and oil into the oil
tank.
Convenient indicator segments indicate
condition of the oil supply. Refer to oil
level indicator.
To fill the engine oil into the engine oil
tank, proceed as follows:
w
Do not add gasoline (Petrol) into the oil
tank. Fire or explosion could result.
Fuel tank capacity: Refer to SPECIFICA-
TIONS, page 4-1.
Engine oil tank capacity: Refer to
“SPECIFICATION”, page 4-1.
902055
6H2-9-7M-3A (GB,F,ES) 5/9/00 4:03 PM Page 10
