Yamaha A15 - A10 Overall Assembly Parts

SPEAKER SYSTEM/SUBWOOFER
2
A10/A12/A12M/A15/A15W
OVERALL ASSEMBLY: A10
: New Parts
REF NO. PART NO. DESCRIPTION REMARKS QTY RANK
RANK: Japan only
OVERALL ASSEMBLY A10
1 Speaker 8ohms 125W 10" WOOFER
5 +Bind Head Tapping Screw D4.0/L16 Black for 10" WOOFER and HANDLE 18
8 Cushion
11 Speaker 8ohms 150W TWEETER 15
12 +Bind Head Tapping Screw D4.0/L25 Black for TW, TERMINAL 10
13 Cushion 110LX14WX1.0T 2
14 Cushion 265LX14WX1.0T 2
15 Metal Grille
20 YAMAHA Logo BADGE
21 Cushion for LOGO
22 Push Nut SPN-4 2 01
23 +Cup Screw D4.0/L16 Black for METAL GRILLE 8 01
24 Metal Handle 05
25 Tripod Support Mount
26 +Flat Head Tapping Screw D5.0/L25 Black for TSM 4
28 Network
33 +Bind Head Tapping Screw D3.0/L20 Black for NETWORK CROSSOVER 4
34 Phone Jack 06
35 Neutrik NL4MP SPEAKON 06
36 Terminal PLATE 2 HOLES, without LABEL
38 Nut for NEUTRIK 2 01
39 +Flat Head Machine Screw M3.0/L12 Black for NEUTRIK 2 01
40 Rubber Foot 4
42 +Bind Head Wood Screw D5.0/L30 for RUBBER FOOT 4
43 Polyswitch RXE050 03
AAX58850
AAX59650
AAX59660
JAY21400
AAX59670
AAX59680
AAX59690
AAX59700
AAX59750
AAX59760
V6290000
WA764400
WA748900
WD887400
AAX59770
AAX59790
VI064700
WA753900
LAY00180
AAX59840
ES200030
V5993400
AAX59860
AAX59870
VV216100
*
*
*
*
*
*
*
*
*
*
*
*
*
*
A
A
BB
A-A
B-B
15
23
15
12
5
23
23
23
12
12
12
39
1 8
5
23
23
11 13 14
15
24
5
5
28
33
43
34
36
35
20
26
25
40
42
40
42
21
22
Push Nut
Input Panel
39
38
35
34
11
Speaker(Tweeter)
