Setting an aspect ratio to output HDMI video signals
Selects an aspect ratio to output HDMI video signals when “Video Mode” is set to
“Processing”.
NOTE
For details on “Video Mode” in the “Setup” menu, see the following:
▪
“Setting the use of the video signal processing” (p.128)
Setup menu
“Video/HDMI” > “Video Mode” > “Aspect”
Settings
Through Does not convert the aspect ratio.
16:9 Normal
Outputs 4:3 video signals to a 16:9 TV with black bands on either side of
the screen.
NOTE
This setting functions only when 480i/576i or 480p/576p signals are converted into 720p, 1080i, 1080p, or
2160p (4K) signals.
Setting the use of HDMI Control
Enables/disables HDMI Control. HDMI Control allows you to operate external devices
via HDMI.
Setup menu
“Video/HDMI” > “HDMI Control” > “HDMI Control”
Settings
Off Disables HDMI Control.
On
Enables HDMI Control.
Configure the settings in “TV Audio Input”, “ARC” and “Standby Sync”.
NOTE
To use HDMI control, you need to perform the HDMI Control link setup after connecting HDMI Control-
compatible devices. For details, see the following:
▪ “HDMI Control and synchronized operations” (p.190)
Setting the audio jack used for TV audio input
Selects an audio input jack of the unit to be used for TV audio input when “HDMI
Control” is set to “On”. The unit’s input source automatically switches to TV audio when
the TV input is switched to its built-in tuner.
NOTE
For details on “HDMI Control” in the “
Setup” menu, see the following:
▪ “Setting the use of HDMI Control” (p.129)
Setup menu
“Video/HDMI” > “HDMI Control” > “TV Audio Input”
Settings
AV 1–2, AUDIO 1–5
NOTE
When using ARC to input TV audio to the unit, the input jacks selected here will be used for TV Audio Input.
Setting the use of ARC
Select whether to output TV audio to the speakers connected to the unit when “HDMI
Control” is set to “On”.
NOTE
For details on “HDMI Control” in the “
Setup” menu, see the following:
▪ “Setting the use of HDMI Control” (p.129)
Setup menu
“Video/HDMI” > “HDMI Control” > “ARC”
Settings
Off Disables ARC.
On Enables ARC.
NOTE
You do not need to change this setting normally. In case noises are produced from the speakers connected
to the unit because TV audio signals input to the unit via ARC are not supported by the unit, set “ARC” to “Off”
and use the TV’s speakers.
En
129

Yamaha AVENTAGE RXA780BL Specifications

General

Audio Channels	7.2
Rated Output Power (1kHz, 1ch driven)	140 W
Maximum Effective Output Power (1kHz, 1ch driven) (JEITA)	140 W
HDMI Inputs	7
HDMI Outputs	2
Dolby Atmos	Yes
DTS:X	Yes
Wi-Fi	Yes
Bluetooth	Yes
Multi-room Audio	Yes
Weight	22.5 kg
Surround Sound Processing	Yes
DSP Programs	24
Dialogue Level Adjustment	Yes
Virtual Presence Speaker	Yes
Virtual Surround Back Speaker	Yes
Dialogue Lift	Yes
SILENT CINEMA / Virtual CINEMA DSP	Yes
Dolby TrueHD	Yes
Dolby Digital Plus	Yes
DTS-HD Master Audio	Yes
AirPlay	Yes
HDMI eARC	Yes
HDMI Pass-Through	Yes
HDMI Upscaling	Yes (4K)
Digital Audio Input/Output: Optical	2 / 0
Digital Audio Input/Output: Coaxial	2 / 0
Phono Input	Yes
Speaker Output Terminals	9
Zone 2 Audio Output	Yes
Zone 3 Audio Output	Yes
AV Front Input	Yes
Headphone Output	1
Tuner Section	FM/AM
Dimensions (W x H x D)	435 x 171 x 329 mm
Video Upscaling	Yes (4K)
Spotify Connect	Yes
DTS Virtual:X	Yes
Rated Output Power (20Hz-20kHz, 2ch driven)	95 W
File Format	MP3, WMA, AAC, WAV
Analog Audio Input/Output	4 / 1
