Yamaha AVENTAGE RXA780BL User Manual

Enjoying audio using Bluetooth® speakers/
headphones
You can enjoy audio played back on the unit using Bluetooth speakers/headphones.
Bluetooth speakers/headphones
The unit
NOTE
▪ Sounds will be also output from the speakers connected to the unit.
▪ AirPlay and DSD audio cannot be delivered.
▪ You cannot use the Bluetooth audio transmitter function and the Bluetooth audio receiver function at the
same time.
1
Use the input selection keys on the remote control to select an
input source.
Select an input source other than Bluetooth.
2
Press SETUP.
3
Use the cursor keys to select “Bluetooth” and press ENTER.
4
Use the cursor keys to select “Audio Send” and press ENTER.
5
Use the cursor keys to select “Transmitter” and press ENTER.
6
Use the cursor keys to select “On” and press RETURN.
7
Use the cursor keys to select “Device Search” and press ENTER
to search the Bluetooth devices.
The list of Bluetooth devices is displayed.
8
Use the cursor keys to display the desired Bluetooth speakers/
headphones and press ENTER.
9
Use the cursor keys and ENTER to check the Bluetooth speakers/
headphones to be connected with the unit.
10
Use the cursor keys to select “CONNECT” and press ENTER.
When the connection process finishes, “Completed” is displayed and
audio played back on the unit will be reproduced from the Bluetooth
speakers/headphones.
NOTE
If the desired Bluetooth device is not displayed on the list, set the Bluetooth device to the pairing
mode and then perform “Device Search” operation again.
11
Press SETUP.
This completes the settings.
NOTE
▪ When the Pure Direct is enabled, input sources other than the network sources and USB cannot be
delivered.
▪ To terminate the Bluetooth connection, perform one of the following operations.
– Perform the disconnect operation on the Bluetooth speakers/headphones.
– Press the SETUP key, then use the cursor keys to select "Bluetooth", then "Transmitter", and then "Off".
En
81

Yamaha AVENTAGE RXA780BL Specifications

General

Audio Channels	7.2
Rated Output Power (1kHz, 1ch driven)	140 W
Maximum Effective Output Power (1kHz, 1ch driven) (JEITA)	140 W
HDMI Inputs	7
HDMI Outputs	2
Dolby Atmos	Yes
DTS:X	Yes
Wi-Fi	Yes
Bluetooth	Yes
Multi-room Audio	Yes
Weight	22.5 kg
Surround Sound Processing	Yes
DSP Programs	24
Dialogue Level Adjustment	Yes
Virtual Presence Speaker	Yes
Virtual Surround Back Speaker	Yes
Dialogue Lift	Yes
SILENT CINEMA / Virtual CINEMA DSP	Yes
Dolby TrueHD	Yes
Dolby Digital Plus	Yes
DTS-HD Master Audio	Yes
AirPlay	Yes
HDMI eARC	Yes
HDMI Pass-Through	Yes
HDMI Upscaling	Yes (4K)
Digital Audio Input/Output: Optical	2 / 0
Digital Audio Input/Output: Coaxial	2 / 0
Phono Input	Yes
Speaker Output Terminals	9
Zone 2 Audio Output	Yes
Zone 3 Audio Output	Yes
AV Front Input	Yes
Headphone Output	1
Tuner Section	FM/AM
Dimensions (W x H x D)	435 x 171 x 329 mm
Video Upscaling	Yes (4K)
Spotify Connect	Yes
DTS Virtual:X	Yes
Rated Output Power (20Hz-20kHz, 2ch driven)	95 W
File Format	MP3, WMA, AAC, WAV
Analog Audio Input/Output	4 / 1
