Yamaha AW4416 Service Manual

AW4416
116
YAMAHA [PROFESSIONAL AUDIO WORKSTATION] Date: 18 Feb. 2000
Model: AW4416
MIDI Implementation Chart
Version: 1.0
Function... Transmitted Recognized Remarks
Basic
Channel
Default
Changed
1–16
1–16
1–16
1–16
Memorized
Memorized
Mode
Default
Messages
Altered
X
X
**************
OMNI off/OMNI on
X
X
Memorized
Note
Number :True Voice
X
**************
0–127
X
Velocity
Note On
Note Off
X
X
X
X
After
Touch
Key’s
Ch’s
X
X
X
X
Pitch Bend X X
Control
Change
XX
Prog
Change :True#
0–127
**************
0–127
0–96
System Exclusive X O *1
System
Common
:Song Pos
:Song Sel
:Tune
O
X
X
X
X
X
*2
System
Real Time
:Clock
:Commands
O
O
X
X
*2
*2
Aux
Messages
:Local ON/OFF
:All Notes OFF
:Active Sense
:Reset
X
X
X
X
X
X
O
O
Notes
MTC quarter frame message is transmitted.(When MTC Sync mode)
MTC quarter frame message is recognized.(When MTC Sync mode)
*1: MMC
*2: When MCLK Sync mode
Mode 1: OMNI ON, POLY
Mode 3: OMNI OFF, POLY
Mode 2: OMNI ON, MONO
Mode 4: OMNI OFF, MONO
O: Yes
X: No

Yamaha AW4416 Specifications

General

Type	Digital Audio Workstation
Mixer Channels	44
Sampling Frequency	44.1 kHz
Bit Depth	24-bit
A/D Conversion	24-bit
D/A Conversion	24-bit
Effects	Yes
Digital I/O	ADAT, S/PDIF
MIDI	In/Out/Thru
Built-in CD-RW Drive	Yes
Tracks	16
Simultaneous Recording Tracks	8
Simultaneous Playback Tracks	16
EQ	4-band parametric
Storage	Internal hard drive
Display	LCD display
Inputs	8 XLR/TRS combo inputs
Faders	17 x 100mm motorized faders
