1. Drain bolt
5. Install the drain bolt, and then tighten it to
the specified torque.
6. Fill the engine with the recommended oil,
and then install the oil filler cap.
cC
8 In order to prevent clutch slippage
(since the engine oil also lubricates the
clutch), do not mix any chemical addi-
tives. Do not use oils with a diesel
specification of “CD” or oils of a higher
quality than specified. In addition, do
not use oils labeled “ENERGY CON-
SERVING II” or higher.
8 Make sure that no foreign material
enters the crankcase.
Tightening torque:
Drain bolt:
20 Nm (2.0 m0kgf, 14 ft0lbf)
Recommended oil:
See page 10-2.
Oil quantity:
Periodic oil change:
1.5 L (1.3 Imp qt, 1.6 US qt)
8-7
