8-22
8. Remove the carburetor cap securing plate
by removing the screw.
9. Loosen the carburetor joint screws.
10. Remove the carburetor cap.
11. Remove the throttle cable from the throttle
valve, and then remove the throttle cable
holder by removing the screws.
1
2
1
1
1
1
1
2
3
4
1. Carburetor cap securing plate 2. Screw
1. Throttle cable 2. Throttle valve 3.
Throttle cable holder
4. Screw (× 2)
1. Joint screw (× 4)
