CDX-596
■
MECHANICAL PARTS
30
Ref.
No. PART NO. Description Remarks Markets
New Parts
*
1-3 MF121160 FLEXIBLE FLAT CABLE 21P 160mm
* 1-20 V4210800 FRONT PANEL BL
* 1-20 V4210900 FRONT PANEL TI
* 1-20 V4411100 FRONT PANEL GD
* 1-21 V4211000 PANEL,SUB BL
* 1-21 V4211100 PANEL,SUB TI
* 1-21 V4413900 PANEL,SUB GD
* 1-22 V4210600 WINDOW PANEL,LID
1-23 V0068200 BUTTON GD
1-23 VZ494400 BUTTON 11x22 BL
1-23 VZ494500 BUTTON 11x22 TI
1-31 V2668300 SUPPORT,HP
1-40 EP630290 BIND HEAD P-TITE SCREW 3x6 FCRM3-BL
* 2 V5004600 P.C.B.ASS'Y MAIN (A)
* 2 V5004700 P.C.B.ASS'Y MAIN (BG)
5 VZ573200 CD MECHANISM UNIT KSL-2130CCM
8 V2296800 POWER CORD ASS'Y (A)
8 VN363700 POWER CORD ASS'Y (G)
8 VV437300 POWER CORD ASS'Y (B)
9 V2438700 CORD STOPPER #10P1
11 V5343800 CONNECTOR,FLAT CABLE 16P 260mm
13 MF706100 CONNECTOR ASS'Y 6P 100mm
14 MF705100 CONNECTOR ASS'Y 5P 100mm
20 VZ151800 CHASSIS,MAIN ALL
* 21 V4410900 REAR PANEL (BG)
* 21 V4629800 REAR PANEL (A)
23 V3081200 TOP COVER GD
23 VZ151900 TOP COVER BL
23 VZ152000 TOP COVER TI
* 26 V4200800 LID,CDX BL
* 26 V4200900 LID,CDX TI
* 26 V4411200 LID,CDX GD
27 V0049900 LEG D60xH16 GD
27 VQ780300 LEG D60xH16 BL,TI
28 VS037900 SHEET,TRAY B
29 V3205000 CARD EDGE SPACER KGES-18
35 VU981200 SUPPORT,P.C.B.No.3596
37 VZ262200 SUPPORT PU
50 VU590000 BINDING TIE CBTD001B
55 V2113100 SPACER
60 21991500 PW HEAD S-TITE SCREW 4x8-10 FCRM3-BL BL
60 VD069600 PW HEAD S-TITE SCREW 4x8-10 MFNI-33 GD
60 VH313200 BW HEAD S-TITE SCREW 4x8-10 FNM3-BL TI
61 EP600250 BIND HEAD B-TITE SCREW 3x8 ZMC2-Y
62 EP630640 BIND HEAD P-TITE SCREW 3x20 FCRM3-BL
63 VN413300 BIND HEAD BONDING B-T.SCREW 3x8 MFZN2-BL
66 EP630400 FLAT HEAD B-TITE SCREW 3x6 FCRM3-BL
67 V2728500 BIND HEAD S-TITE SCREW 4x7 MFZN2-BL
69 EP600830 BIND HEAD B-TITE SCREW 3x8 FCRM3-BL
70 V2128100 PW HEAD S-TITE SCREW 3x12-8 MFZN2-Y
71 VT669300 PW HEAD B-TITE SCREW 3x8-8 MFC2
ACCESSORIES
* 200 V4926000 REMOTE CONTROL TRANSMITTER CDX4
200-1 AAX13340 LID BLJYE 60050001
VS381600 PIN-PLUG CORD 2P 1.0m
BATTERY,MANGANESE SUM-3,AA,R06
