6-2. MC SHEET TEST
=TEST MODE=
MC SHEET
(↓,↑,→)
(1) MC SHEET Version
Ver 0.2.0
(2) SDRAM Read Test
Push PLAY Ke
y
(3) FLASH R/W Test
Push PLAY Ke
y
(4) FLASH Read Test
Push PLAY Key
(5) DIGITAL I/O Test
Push PLAY Ke
y
(6) CD-ROM Read Test
Push PLAY Ke
y
(7) USB Read Test
Push PLAY Key
(8) NAND Read Test
Push PLAY Ke
y
(9) ETHERNET Test
Push PLAY Ke
y
(2) SDRAM Read Test
OK !
(3) FLASH R/W Test
OK !
(4) FLASH Read Test
OK !
(5) DIGITAL I/O Test
OK !
(6) CD-ROM Read Test
OK !
(7) USB Read Test
OK !
(8) NAND Read Test
OK !
(9) ETHERNET Test
OK ! 00A0DE:4D****
← →
Displays the version number of MC sheet.
Insert a CD-ROM to the CD drive.
Press [PLAY/PAUSE] button.
Insert a USB memory to the [USB TO
DEVICE] port. And press [PLAY/PAUSE]
button.
Connect the LAN. Press the [PLAY/PAUSE] button.
MAC address should be displayed in the lower light.
Check that it starts with “00A0DE:4D”.
NAND Flash memory test.
