6-3. APE SHEET TEST
=TEST MODE=
APE SHEET
(↓,↑,→)
0:APE Sheet Version
APE V2.00 (20090123)
(←,→)
1:DSP RAM R/W Test
Press [PLAY]
(←,→)
2:DSP Flash Read test
Press [PLAY]
(←,→)
3:APE Audio Test Signal
Playing Test Signal[L ]
(←,→)
4:APE Audio Input test
AnalogMIDI IN ->OUTPUT
(←,→)
5:APE XG Tone Test
Playing XG Tone
(←,→)
6:APE SPDIF Test
CSP Locked
AME Unlocked (←,→)
7:APE D-SUB Test
(←,→)
1:DSP RAM R/W Test
Press [PLAY]
RAM Test is OK ! (←,→)
2:DSP Flash Read test
Press [PLAY]
Flash Test is OK! (←,→)
3:APE Audio Test Signal
Playing Test Signal[ ]
(←,→)
3:APE Audio Test Signal
Playing Test Signal[ R]
(←,→)
4:APE Audio Input test
OMNI IN ->OMNI OUT
(←,→)
← →
Displays the version number of APE sheet.
Check in turn if sound is outputted from the OUTPUT
and OMNI OUT.
Sound will be outputted from the OUTPUT if audio signal
is inputted from the Analog MIDI IN.
A
nd outputted from the OMNI OUT if inputted from the
OMNI IN.
Check if drum sound are outputted from the OUTPUT.
Not be used.
Not be used.
