Yamaha E40GMH User Manual

9-12
CONVENTIONAL RIGGING KIT CONTENTS
REMOTE OIL TANK KIT (FOR 2-STROKE ENGINE)
10.5 L (2.8 US-GAL) TANK
Global P/N: 6YR-W0035-D2
US/CA P/N: 6YR-W0035-94
Part name Part No. Q’ty Remarks
Remote oil tank ASSY 61A-21708-20 1
Remote oil tank holder 6E5-21734-01 1
Damper 6E5-21746-00 2
Bracket 6E5-21798-01 1
Fuel pipe complete 6YK-24307-42 1
Clamp 90450-10M07 1
Clamp 90465-11M10 1
Clamp 90465-13M11 1
Washer 92990-06600 2
Nut 95380-06600 1
Bolt 97080-06100 1
Part name Part No. Q’ty Remarks
Remote oil tank ASSY 61A-21708-20 1
Remote oil tank holder 6E5-21734-01 1
Damper 6E5-21746-00 2
Bracket 6E5-21798-01 1
Fuel pipe complete 6Y2-24307-50 1 Meeting with ABYC requirements
Clamp 90450-10M07 1
Clamp 90465-11M10 1
Clamp 90465-13M11 1
Washer 92990-06600 2
Nut 95380-06600 1
Bolt 97080-06100 1

Yamaha E40GMH Specifications

General

Engine Type	2-Stroke
Fuel Induction System	Carburetor
Starting System	Manual
Ignition System	CDI
Lubrication System	Premix
