SPECIFICATIONS
EAU50970
Dimensions:
Overall length:
1565 mm (61.6 in)
Overall width:
600 mm (23.6 in)
Overall height:
990 mm (39.0 in)
Seat height:
745 mm (29.3 in)
Wheelbase:
1080 mm (42.5 in)
Ground clearance:
110 mm (4.33 in)
Minimum turning radius:
1700 mm (66.9 in)
Weight:
Curb weight:
56 kg (123 lb)
Chassis:
Frame type:
Backbone
Caster angle:
25.00 
Trail:
75 mm (3.0 in)
Front tire:
Type:
With tube
Size:
60/100-12 36J
Manufacturer/model:
INOUE RUBBER/MB80
Rear tire:
Type:
With tube
Size:
60/100-12 36J
Manufacturer/model:
INOUE RUBBER/MB80
Maximum load:
87 kg (192 lb)
* (Total weight of rider, cargo and accesso-
ries)
Tire air pressure (measured on cold
tires):
Front:
200 kPa (2.00 kgf/cm
2
, 29 psi)
Rear:
250 kPa (2.50 kgf/cm
2
, 36 psi)
Front wheel:
Rim size:
12 x 1.50
Rear wheel:
Rim size:
12 x 1.50
Front brake:
Type:
Drum brake
Operation:
Right hand operation
Rear brake:
Type:
Drum brake
Operation:
Left hand operation
Front suspension:
Type:
Telescopic fork
Spring/shock absorber type:
Coil spring
Wheel travel:
50.0 mm (1.97 in)
Rear suspension:
Type:
Unit swing
Spring/shock absorber type:
Coil spring/oil damper
Wheel travel:
55.0 mm (2.17 in)
Headlight:
Bulb type:
Halogen bulb
Bulb voltage, wattage  quantity:
Headlight:
12 V, 35 W/35 W  1
Tail/brake light:
12 V, 5.0 W/21.0 W  1
Front turn signal light:
12 V, 10.0 W  2
Rear turn signal light:
12 V, 10.0 W  2
Warning indicator light:
LED
