DESCRIPTION
1 Carrying handle
2 Fuel tank cap air vent knob
3 Fuel tank cap
4 Recoil starter
5 Fuel gauge
6 Muffler
7 Oil filler cap
AE00103
Control panel
1 Oil warning light
2 AC pilot light
3 Overload indicator light
4 Economy control switch
(Black)
5 Engine switch (Red)
6 Fuel cock knob
7 Choke knob
8 Twin Tech (parallel running
terminal)
9 AC receptacle
0 DC protector (breaker)
q Ground (earth) terminal
w DC receptacle
123 45
6
7
8
9
0q
w
