– 19 –
Battery charging
Do not connect a VRLA (Valve Regulated Lead
Acid) battery. To charge a VRLA battery, a special
(constant-voltage) battery charger is required.
TIP
9 The generator DC rated voltage is 12V.
9 Start the engine first, and then connect the gener-
ator to the battery for charging.
9 Before starting to charge the battery, make sure
that the DC protector is turned on.
1. Start the engine.
6v 6v
12v
762-041
2. Connect the red battery charger lead to the posi-
tive (+) battery terminal.
1 Red wire
2 Black wire
3. Connect the black battery charger lead to the neg-
ative (-) battery terminal.
4. Turn the economy control switch off to start battery
charging.
7DK-9-11_a 11.3.21 15:19 Page 19
