Yamaha EF2000iS - Engine Oil Check and Fill

– 13 –
1 Upper level
5. Install the cover and tighten the screws.
7DK-031
1
7DK-033
700-119
1
AE00222
Engine oil
The generator has been shipped without engine oil.
Do not start the engine until you have filled it with
the sufficient engine oil.
1. Place the generator on a level surface.
2. Remove the screws 1, and then remove the cover
2.
NOTICE
1
2
7DK-030
4. Fill the specified amount of the recommended
engine oil, and then install and tighten the oil filler
cap.
Recommended engine oil:
å
YAMALUBE 4 (10W-40),
SAE 10W-30 or 10W-40
∫
SAE #30
ç
SAE #20
∂
SAE 10W
Recommended engine oil grade:
API Service SE type or higher
Engine oil quantity:
0.4 L (0.42 US qt, 0.35 lmp qt)
0°C
å
YAMALUBE 4 (10W-40)
∂
SAE 10W
ç
SAE #20
∫
SAE #30
32°F
25°C
80°F
3. Remove the oil filler cap 1.
