G-440
CONNECTION
G-44904
Alternating Current (AC)
cC
9 Be sure all electric apparatuses including the
lines and plug connections are in good condi-
tion before connection to the generator.
9 Be sure the electric apparatus is turned off
before plugging it in.
9 Be sure the total load is within generator rated
output.
9 Be sure the socket load current is within sock-
et rated current.
1. Wind the power lead 2 or 3 turns around
frame
2. Start the engine.
3. Plug into AC socket.
4. Turn the AC switch to the “ON” position and
turn on the electric apparatus.
1 I “ON”
A for EF2600A
B for EF4600A/EF6600A
AC 120V can be used.
C for EF4600A/EF6600A
AC 120V and 240V can be used.
cC
Reduce the load to the specified generator rated
output if the AC switch turns off.
If it turns off again, consult a Yamaha dealer.
– 15 –
A
To Next Page
