P OK
O Clogged
Engine does not
start.
C Does not start D Engine starts.
B
– 26 –
G-67004
A ENGINE DOES NOT START
Turn the engine switch and fuel clock
lever to the “ON” position and then
pull the recoil starter.
H
Pull the recoil starter and check the
spark plug for spark strength.
(See “WARNING”)
w
9 To prevent FIRE HAZARDS be
sure fuel is not present in the
spark plug area.
9 To prevent FIRE HAZARDS be
sure to place the spark plug as far
way as possible from the spark
plug hole and carburetor area.
9 To prevent ELECTRIC SHOCK do
not hold spark plug lead with
hand while testing.
Engine starts.
I J
Check the following
9 Fuel cock clogging
9 Air cleaner element
clogging.
N
Clean or Replace; Consult a
Yamaha dealer.
Q
R Consult a Yamaha dealer.
K Check the spark plug.
9 Type:
9 Gap:
L Incorrect M OK
Replace or
Adjust Gap.
Clean the spark
plug.
E Check engine oil level.
F OK G Level low
Consult a
Yamaha dealer.
Add engine oil.
To Next Page
