– 45 –
Air Filter
1. Remove the screws, and then remove the air filter
case cover.
2. Remove the foam element.
1 Screw
2 Air filter case cover
3 Foam element
3. Wash the foam element in white kerosene and dry
it.
WARNING
Never use white kerosene while smoking or in the
vicinity of an open flame.
4. Oil the foam element and squeeze out excess oil.
The foam element should be wet but not dripping.
Recommended oil:
Foam-air-filter oil or engine oil (See page 42)
NOTICE
Do not wring out the foam element when squeez-
ing it. This could cause it to tear.
5. Insert the foam element into the air filter case.
TIP
Be sure the foam element sealing surface matches the
air filter case so there is no air leak.
NOTICE
The engine should never run without the foam ele-
ment; excessive piston and cylinder wear may
result.
6. Install the air filter case cover and tighten the
screws.
710-037a
2
1
1
3
7P5-F8199-14.indd 45 2021/06/23 11:22:19
