ELS-01/01C Owner’s Manual
96
Music Data Recorder (MDR)
7
The M.D.R. display consists of two display pages: the SONG Page and the TOOLS
Page. In the SONG Page, you can select a song, then play it back or record it. The
TOOLS Page has a variety of song utility operations, such as copy, delete, rename, etc.
Pressing the [SONG] or [TOOLS] button at the top right of the display switches
between the SONG Page and the TOOLS Page.
1 Current Media/Folder
Displays the currently selected media and folder(s). The left side of the indication
(before “:/”) shows the particular media and the right side shows the path with
currently selected folder name at the end. For example, “USB 01:/Folder1/” indicates
that the folder named “Folder1” contained in the USB flash memory is selected.
2 Media/Folder/Song List
Displays the media, folders or songs. Up to 120 folders can be displayed (5 folders at
once).
3 Scroll Buttons
If the Media/folder/Song List contains more than 5 media/folders/songs, you can scroll
through the display with these buttons.
4 SETTINGS
Displays/changes the settings for the currently selected song.
5 UP
Selects the higher layer folder or media. For example, when “USB 01:/Folder1/”
(Folder1 in the USB flash memory) is selected, pressing the [UP] button selects “USB
01:/” (USB flash memory).
2
Using the LCD Display
1
789)@ #$%^&!
23 554 6
SONG Page TOOLS Page
Reference Page
Setting a song (page 104)
