3
EV-204 / EV-205
SPECIFICATIONS
Neck Hard Maple
Fingerboard/Nut Ebony
Bridge Single Unit with Pickup
Body Frame Maple
Sound Board Maple
Chin Rest Ebony
Tailpiece EV-204 : Ebony (4 hole type)
EV-205 : Ebony (5 hole type)
Tuning Pegs Gear Type
Strings EV-204 : YAMAHA strings (EV4S)
EV-205 : YAMAHA strings (EV5S)
Pickup Individual high power output pickup for each string
Connectors/Controls • MODE Select Switch
(CONTROLLED (Active)/DIRECT (Passive))
• MASTER VOLUME
• LINE OUT
(with the power “ON” and a cable connected)
• OUTPUT IMPEDANCE: LINE OUT 0~500kΩ
• Pickup Level Controls (Available to ‘CONTROLLED’ mode)
EV-204 : 4ch Mixer & Main Volume
EV-205 : 5ch Mixer & Main Volume
• PHONES (POWER ON when a plug is inserted.)
• PHONES VOLUME
Power Supply 6F22 (S-006P) 9V battery x1
Battery Life Used with headphones
(MODE=CONTROLLED, Continuous Use)Manganese battery: approximately 6.5 hours
Alkaline battery: approximately 15 hours
Used without headphones
Manganese battery: approximately 8 hours
Alkaline battery: approximately 18 hours
String Length 328 mm (12-15/16”)
Dimensions EV-204 : 589 (L) x 206 (W) x 126 (H) mm
23-3/16” (L) x 8-1/8” (W) x 4-15/16” (H)
EV-205 : 601 (L) x 206 (W) x 132 (H) mm
23-11/16” (L) x 8-1/8” (W) x 5-3/16” (H)
Weight (with battery) EV-204: 700g (1 lbs. 8 oz.)
EV-205: 717g (1 lbs. 9 oz.)
Color AMBER, PEARL RED, COSMIC BLUE
