< Table 11 >
Current Voice / Element Bulk
Address Size Data Parameter Description
(H) (H) (H)
60 ee 00 1 00 - C4 Wave Bank/Element Type
1 00 - 7F Element Volume
2 00 00 - 0F FF Wave Number
1 00 - FF Random PAN/PAN(Random Depth)
1 00 - FF Release Loop/O.S./Revs/Vce/Scaling PAN Depth
1 00 - 7F Tune Fine
1 00 - 7F Tune Coarse
1 35 - CB Detune
1 00 - 7F Note Limit (Low)
1 00 - 7F Note Limit(High)
1 00 - 7F Note Cross Fade
1 00 - 7F Velocity Limit(Low)
1 00 - 7F Velocity Limit(High)
1 00 - 7F Velocity Cross Fade
1 00 - 7F ExpressionLimit Low
1 00 - 7F Key On Delay
1 00 - FF LFO Wave/Frequency
1 00 - FF PMD
1 00 - FF PINV/AMD
1 00 - FF CINV/CMD
1 00 - FF Sync/Delay Vibrato Start Time
1 00 - FF LFO Fade Time
1 00 - FE Freq Random Sense/Freq Vel Sense
1 00 - 3F LFO Freqency
1 00 - 1F Wave Phase/LFO Wave
1 00 - 7F LFO Destination No.
1 00 - 7F LFO Depth
1 00 - FF Sync/Delay Vibrato Start Time
1 00 - FF LFO Fade Time
1 00 - FF Micro Tuning Table No./Pitch Scaling
1 00 - 7F Pitch Scaling Center Note
1 00 - FF Initial Level(cent)
1 00 - FF 1st Level(cent)
1 00 - FF 2nd Level(cent)
1 00 - FF 3rd Level(cent)
1 00 - FF Release1 Level(cent)
1 00 - FF Release2 Level(cent)
1 00 - 7F Pitch EG Depth
1 00 - 7F Hold Time
1 00 - 7F 1st Rate
1 00 - 7F 2nd Rate
1 00 - 7F 3rd Rate
1 00 - 7F Release1 Rate
1 00 - 7F Release2 Rate
1 00 - 3E Loop Segment/PEG Rate Scaling Sense
1 00 - FE Pitch Random Sense/I.Touch->IHR Sense
1 00 - EE I.Touch->1st Rate sense/I.Touch->Other Rates Sense
1 00 - 0E I.Touch->PEG Level Sense
1 00 - FF Initial Level
1 00 - FF EGmode/AR,IHR
1 00 - 7F D1R
1 00 - FF D1L
1 00 - 7F D2R
1 00 - FF D2L
1 00 - 7F D3R
1 00 - FF D3L
1 00 - FF RR1mode/Release Rate
1 00 - FF R1L
1 00 - 7F Release2 Rate
1 00 - 7F Level Scaling Break Point 1
1 00 - 7F Level Scaling Break Point 2
1 00 - 7F Level Scaling Break Point 3
1 00 - 7F Level Scaling Break Point 4
1 00 - FF Level Scaling Offset 1
1 00 - FF Level Scaling Offset 2
1 00 - FF Level Scaling Offset 3
1 00 - FF Level Scaling Offset 4
1 00 - 7F Level Scaling Sense
1 00 - 7F I.Touch Level Sense
1 00 - EE I.Touch->DL Sense/I.Touch->IHR Sense
1 00 - EE Rate Scaling Sense/I.Touch->AR Sense
1 00 - EE I.Touch->D1R Sense/I.Touch->Other Rate Sense
1 00 - 5F Cnct/Q
1 00 - FF FEG Level init
1 00 - FF 1st Fc offset
1 00 - FF 2nd Fc offs
1 00 - FF 3rd Fc offs
1 00 - FF Release1 Fc offs
1 00 - FF Release2 Fc offs
1 00 - 7F FEG Initail Hold Rate
1 00 - 7F FEG 1st Rate
1 00 - 7F FEG 2nd Rate
1 00 - 7F FEG 3rd Rate
1 00 - 7F FEG Release1 Rate
1 00 - 7F FEG Release2 Rate
1 00 - 3E Loop Segment/PEG Rate Scaling Sense
1 00 - EE I.Touch->Q Level Sense/I.Touch->IHR Sense
1 00 - EE I.Touch->1st Rate Sense/I.Touch->Other Rate Sense
1 00 - 7F Q enable/LFO/FEG enable/Filter Type
1 00 - FF Fc
1 00 - FF Gain
1 00 - 7F Filter Scaling Break Point 1
1 00 - 7F Filter Scaling Break Point 2
1 00 - 7F Filter Scaling Break Point 3
1 00 - 7F Filter Scaling Break Point 4
1 00 - FF Filter Scaling Offset 1
1 00 - FF Filter Scaling Offset 2
1 00 - FF Filter Scaling Offset 3
1 00 - FF Filter Scaling Offset 4
1 00 - 7F Fc scaling sense
1 00 - EE I.Touch->Gain Sense/I.Touch->Fc Sense
1 00 - FE Fc Random Sense/I.Touch->FEG Level Sense
1 00 - 7F FEG Depth
1 00 - 7F Q enable/LFO/FEG enable/Filter Type
1 00 - FF Fc
1 00 - FF Gain
1 00 - 7F Filter Scaling Break Point 1
1 00 - 7F Filter Scaling Break Point 2
1 00 - 7F Filter Scaling Break Point 3
1 00 - 7F Filter Scaling Break Point 4
1 00 - FF Filter Scaling Offset 1
1 00 - FF Filter Scaling Offset 2
1 00 - FF Filter Scaling Offset 3
1 00 - FF Filter Scaling Offset 4
1 00 - 7F Fc scaling sense
1 00 - EE I.Touch->Gain Sense/I.Touch->Fc Sense
1 00 - FE Fc Random Sense/I.Touch->FEG Level Sense
1 00 - 7F FEG Depth
1 00 - 08 Static Filter Type
1 00 - FF Freq 1
1 00 - 7F Boost/Cut 1
1 00 - 1F Q or Band Width
1 00 - EE I.Touch->Boost or Cut1 Sense/I.Touch->Fc1 Sense
1 00 - 77 Boost or Cut Random Sense/Fc Random Sense
1 00 - FF Freq 2
1 00 - 7F Boost/Cut 2
1 reserve
1 00 - EE I.Touch->Boost or Cut2 Sense/I.Touch->Fc2 Sense
1 00 - 7F Fc Scaling Sense
1 00 - 7F Gain
1 00 - 42 FDSP Sw/Ins Sw
ee = Element No.(00 - 7F : Element1 - Element128)
NET SIZE 132
GROSS SIZE 152
< Table 12 >
Voice Bulk
Address Size Data Parameter Description
(H) (H) (H)
5b
00
nn
Conforms to <Table10>.
b = Bank No.(1 - 4 : Preset1,Preset2,Intternal1,Internal2)
nn = Memory No.(00 - 7F : Voice1 - Voice128)
NET SIZE MAX 764(Normal Voice) , 17132(Drum Voice)
GROSS SIZE MAX 880(Normal Voice) , 19584(Drum Voice)
Ignores Preset1/Preset2 reception.
< Table 13 >
Remote SW
Address Size Data Parameter Description
(H) (H) (H)
0A 00 00 1 00 - 01 F1 OFF/ON
01 1 00 - 01 F2 OFF/ON
02 1 00 - 01 F3 OFF/ON
03 1 00 - 01 F4 OFF/ON
04 1 00 - 01 F5 OFF/ON
05 1 00 - 01 F6 OFF/ON
06 1 00 - 01 F7 OFF/ON
07 1 00 - 01 F8 OFF/ON
08 1 00 - 01 TEN KEY 0 OFF/ON
09 1 00 - 01 TEN KEY 1 OFF/ON
0A 1 00 - 01 TEN KEY 2 OFF/ON
0B 1 00 - 01 TEN KEY 3 OFF/ON
0C 1 00 - 01 TEN KEY 4 OFF/ON
0D 1 00 - 01 TEN KEY 5 OFF/ON
0E 1 00 - 01 TEN KEY 6 OFF/ON
0F 1 00 - 01 TEN KEY 7 OFF/ON
10 1 00 - 01 TEN KEY 8 OFF/ON
11 1 00 - 01 TEN KEY 9 OFF/ON
12 1 00 - 01 TEN KEY - OFF/ON
13 1 00 - 01 ENTER OFF/ON
14 1 00 - 01 EXIT OFF/ON
15 1 00 - 01 SHIFT OFF/ON
16 1 00 - 01 DEC OFF/ON
17 1 00 - 01 INC OFF/ON
18 1 00 - 01 RIGHT OFF/ON
19 1 00 - 01 LEFT OFF/ON
1A 1 00 - 01 DOWN OFF/ON
1B 1 00 - 01 UP OFF/ON
1C 1 00 - 01 DATA/CURSOR OFF/ON
1D 1 00 - 01 CANCEL OFF/ON
1E 1 00 - 01 SCENE 1 OFF/ON
1F 1 00 - 01 SCENE 2 OFF/ON
20 1 00 - 01 VOICE OFF/ON
21 1 00 - 01 PERFORMANCE OFF/ON
22 1 00 - 01 SONG OFF/ON
23 1 00 - 01 PATTERN OFF/ON
24 1 00 - 01 SAMPLE OFF/ON
25 1 00 - 01 EDIT OFF/ON
26 1 00 - 01 JOB OFF/ON
27 1 00 - 01 STORE OFF/ON
28 1 00 - 01 UTILITY OFF/ON
29 1 00 - 01 DISK OFF/ON
2A 1 00 - 01 ARPEGGIO OFF/ON
2B 1 00 - 01 KNOB MODE OFF/ON
2C 1 00 - 01 KEY MAP OFF/ON
2D 1 00 - 01 EF BYPASS OFF/ON
2E 1 00 - 01 TOP OFF/ON
2F 1 00 - 01 REW OFF/ON
